M29F800AB-70N6

TSOP, 8 Mbit, non-volatile memory, M29F800AB-70N6, -5.6 to 6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.72~1.11 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.72~1.11

PartNumber:: M29F800AB-70N6

Brand:: STMicroelectronics - ST | Pack: TSOP | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Olivia's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-25

From Other Seller

Part Number:M29F800AB-70N6
US $0.72 - 1.11
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The M29F800AB-70N6 is an 8 Mbit non-volatile memory that can be read, erased and reprogrammed. These operations can be performed using a single 5V supply. On power-up the memory defaults to its Read mode where it can be read in the same way as a ROM or EPROM.

Parametrics

M29F800AB-70N6 absolute maximum ratings: (1)TBIAS, Temperature Under Bias: -50 to 125 ℃ (2)TSTG, Storage Temperature: -55 to 150 ℃ (3)VIO, Input or Output Voltage: -5.6 to 6 V; (4)VCC, Supply Voltage: -5.6 to 6 V; (5)VID, Identification Voltage: -5.6 to 13.5 V.

Features

M29F800AB-70N6 features: (1)SINGLE 5V±10% SUPPLY VOLTAGE for PROGRAM, ERASE and READ OPERATIONS; (2)ACCESS TIME: 70ns; (3)PROGRAMMING TIME: 8ms per Byte/Word typical; (4)19 MEMORY BLOCKS: 1 Boot Block (Top or Bottom Location); 2 Parameter and 16 Main Blocks; (5)PROGRAM/ERASE CONTROLLER: Embedded Byte/Word Program algorithm; Embedded Multi-Block/Chip Erase algorithm; Status Register Polling and Toggle Bits; Ready/Busy Output Pin; (6)ERASE SUSPEND and RESUME MODES: Read and Program another Block during Erase Suspend; (7)TEMPORARY BLOCK UNPROTECTION MODE; (8)LOW POWER CONSUMPTION: Standby and Automatic Standby; (9)100,000 PROGRAM/ERASE CYCLES per BLOCK; (10)20 YEARS DATA RETENTION: Defectivity below 1 ppm/year; (11)ELECTRONIC SIGNATURE: Manufacturer Code: 0020h; M29F800AT Device Code: 00ECh; M29F800AB Device Code: 0058h.
