Product Summary
The TLP582 is a detector. It consists of a GaAlAs light emitting diode and integrated high gain, high speed phptpdetector. The detector has a totem pole output circuit that provides source drive and sink drive, and built-in Schmitt trigger. A fiber is used for light-coupling between LED and detector, and for sufficient separation between input side and output side.
Parametrics
TLP582 absolute maximum ratings: (1)operating temperature range, Topr: -40~85℃ (2)storage temperature range, Tstg: -40~100℃ (3)lead solder temperature (10s), Tsol: 260℃.
Features
TLP582 features: (1)input current: IF=5mA(max); (2)power supply voltage: VCC=4.5~20V; (3)switching speed: tpHL, tpLH=400ns(max); (6)guaranteed performance over temperature: -25~85℃ (7)isolation voltage: 5000Vrms(min).
