Product Summary
The 1812SMS-R10JLC is a Midi Spring Air Core Inductor.
Parametrics
1812SMS-R10JLC absolute maximum ratings: (1)Weight 0.10 – 0.16 g; (2)Terminations RoHS compliant tin-silver over copper. Other terminations available at additional cost; (3)Ambient temperature –40℃ to +125℃ with Irms current, +125℃ to +140℃ with derated current; (4)Storage temperature Component: –40 to +140℃. Packaging: –40℃ to +80℃; (5)Resistance to soldering heat Max three 40 second reflows at +260℃, parts cooled to room temperature between cycles; (6)Temperature Coefficient of Inductance (TCL) +5 to +70 ppm/℃; (7)Moisture Sensitivity Level (MSL) 1 (unlimited floor life at <30℃ /85% relative humidity); (8)Failures in Time (FIT) / Mean Time Between Failures (MTBF) One per billion hours / one billion hours, calculated per Telcordia SR-332; (9)Packaging 500/7 reel; 2000/13 reel Plastic tape: 12 mm wide, 0.3 mm thick, 8 mm pocket spacing, 4.2 mm pocket depth; (10)PCB washing Only pure water or alcohol recommended.
Features
1812SMS-R10JLC features: (1)Air core inductors feature high Q and current handling; (2)Acrylic top provides a flat surface for pick and place; (3)Solder coated leads ensure reliable soldering.
Diagrams
 |
