Product Summary

The 564R60GAT22 is a high voltage capacitor. It consists of a ceramic disc of which both sides are silver-plated. Connection leads are made of tinned copper having diameters of 0.025" (0.64 mm) or 0.032"(0.81 mm). The capacitor may be supplied with straight leads having lead spacing of 0.250" (6.35 mm), 0.375" (9.5 mm) or 0.500" (12.7 mm).

Parametrics

564R60GAT22 specifications: (1)Product Category: Ceramic Disc Capacitors; (2)Capacitance: 220 pF; (3)Tolerance: 20 %; (4)Voltage Rating: 6 KVolts; (5)Termination Style: Radial; (6)Product: High Voltage Ceramic Disc Capacitors; (7)Lead Spacing: 9.52 mm; (8)Packaging: Bulk; (9)Series: 564R; (10)Standard Pack Qty: 250.

Features

564R60GAT22 features: (1)Low losses; (2)High capacitance in small size; (3)High stability.

Diagrams

564R60GAT22 dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
564R60GAT22
564R60GAT22
Vishay/Cera-Mite
Ceramic Disc Capacitors 220pF 6Kvolts 20%
Data Sheet
0-1: $0.44
1-10: $0.40
10-25: $0.38
25-50: $0.37
564R60GAT22AM
564R60GAT22AM

CAP CER 220PF 6KV 20% RADIAL
Data Sheet
0-1000: $0.24
