EP3SL50F780C4N

Programmable Logic Device, FPGA, BGA, Altera Corporation, EP3SL50F780C4N, -0.5 to 1.65V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $72.22~138.89 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $72.22~138.89

PartNumber:: EP3SL50F780C4N

Brand:: Altera Corporation - ALTR | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Olivia's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-25

From Other Seller

Part Number:EP3SL50F780C4N
US $72.22 - 138.89
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The EP3SL50F780C4N is an FPGA. It belongs to Stratix III FPGA family. When EP3SL50F780C4N is implemented in a system, it is rated according to a set of defined parameters. To maintain the highest possible performance and reliability of the EP3SL50F780C4N, system designers must consider the operating requirements described in this chapter. It is offered in both commercial and industrial grades. Commercial devices are offered in –2(fastest), –3, –4, and –4L speed grades.

Parametrics

EP3SL50F780C4N absolute maximum ratings: (1)Selectable core voltage power supply:-0.5 to 1.65V; (2)I/O registers power supply:-0.5 to 1.65V; (3)Phase-locked loop (PLL) digital power supply:-0.5 to 1.65V; (4)PLL analog power supply:-0.5 to 3.75V; (5)Programmable power technology power supply:-0.5 to 3.75V; (6)Configuration pins power supply:-0.5 to 3.9V; (7)I/O pre-driver power supply:-0.5 to 3.9V; (8)I/O power supply:-0.5 to 3.9V; (9)Differential clock input power supply (top and bottom I/O banks only):-0.5 to 3.75V; (10)Battery back-up power supply for design security volatile key register:-0.5 to 3.75V; (11)DC Input voltage:-0.5 to 4.0V; (12)Operating junction temperature:-55℃ to 125℃; (13)DC output current, per pin:-25 to 40mA; (14)Storage temperature:-65℃ to 150℃.

Features

EP3SL50F780C4N features: (1)VCC_CLKIN current specifications:0 to 250mA; (2)VCCPGM current specifications:0 to 250mA; (3)Selectable core voltage power supply for internal logic and input buffers:1.05 to 1.15V; (4)Selectable core voltage power supply for internal logic and input buffers:0.86 to 0.94V; (5)I/O registers power supply:1.05 to 1.15V; (6)PLL digital power supply:1.05 to 1.15V; (7)PLL analog power supply:2.375 to 2.625V; (8)Power supply for the programmable power technology:2.375 to 2.625V.
